C091 51G008 100 2 U

Description
Female panel connector 8 pole IP69K; solder; silver; screw locking
IP-class mated
IP69k
number of positions (w/o PE)
8
rated current (40 °C)
7 (A)
rated voltage
100 (V)
active


7,60 €
price
Total price
380,00 €
Your net plus VAT
pcs.
The minimum order amount is 50 pcs.; packing unit 50 pcs.
Check availability

General Characteristics
contact diameter 1,5 mm
gender female
IP-class mated IP69k
locking system screw coupling
number of positions (w/o PE) 8
part category female receptacle
termination solder pin
Further Characteristics
max. wire gauge 0.5
min. wire gauge 0.05
RoHS Compliant Yes X
Electrical Characteristics
rated current (40 °C) (A) 7
rated voltage (V) 100
Downloads
c091-51g008-100-2-unxc001-01-c3d.stp
m-c091-51g008-x00-2-ucdr000-01-cdr.pdf
m-c091-51g008-100-2-u-rev02-cdr.pdf

Compatible accessory
