| General Characteristics | ||
|---|---|---|
| contact diameter | 3,6 mm | |
| gender | male | |
| IP-class mated | IP67 | |
| number of positions (w/o PE) | 6 | |
| part category | male insert | |
| termination | crimp | |
| Further Characteristics | ||
| lower temperature | (GC) | -25 |
| max. wire gauge | 10 | |
| min. wire gauge | 1.5 | |
| RoHS Compliant Yes | X | |
| upper temperature | (GC) | 125 |
| Electrical Characteristics | ||
| rated current (40 °C) | (A) | 60 |
| rated voltage | (V) | 630 |
| Downloads | |
|---|---|
| m-c148-10a006-000-1-rev01-cdr.pdf | |
| c148-10a006-0001nxc001-01-214-c3d.stp | |
