| General Characteristics | ||
|---|---|---|
| contact diameter | 3,6 mm | |
| gender | male | |
| IP-class mated | IP20 | |
| number of positions (w/o PE) | 3 | |
| part category | male module | |
| termination | crimp | |
| Further Characteristics | ||
| lower temperature | (GC) | -40 |
| max. wire gauge | 10 | |
| min. wire gauge | 1.5 | |
| RoHS Compliant Yes | X | |
| upper temperature | (GC) | 125 |
| Electrical Characteristics | ||
| rated current (40 °C) | (A) | 70 |
| rated voltage | (V) | 1000 |
| Downloads | |
|---|---|
| ce-certificate-c146m-crt.pdf | |
| c146-a03-801-e8c3d001-01-c3d.stp | |
| c146-a03-801-e8nxc001-02-c3d.stp | |
| m-c146-a03-801-e8-rev03-cdr.pdf | |
